Product Details:
Payment & Shipping Terms:
|
| Item Name: | Cast Iron Large Diameter Ring Gear On Grinding Mill Machine | Diameter: | 2000-8000mm |
|---|---|---|---|
| Material: | ZG35CrMo/42CrMo | Processing Type: | Casting |
| After-sales Service Provided: | Proving Overseas Service From Engineers | Weight: | 1-20T |
| Certificate: | ISO 9001:2000 | Application Range: | Rotary Cement Kiln |
| Export Areas: | Russia, Southeast Asia, India,South Africa, Australia | Hardness: | <=HB217 |
| Port: | Tianjin, Shanghai, Qingdao And Others | ||
| High Light: | Cnc Machining Planetary Gear System,8000mm Planetary Gear System,2000mm planetary gear unit |
||
| Specification | |
| Item | 42crnimo4 alloy steel gear |
| Pressure angle | Customized |
| Material | Die steel, alloy steel, stainless steel, etc. |
| Application | Cement kiln, mechanical facilities, etc. |
| Packing | Seaworthy plywood packaged on stell pallets or as customers’ request |
| Delivery date | Depends on the amount and dimension of products |
Processing:
manufacturing process is: forging blank → normalizing → blank inspection → rough aperture, chamfering Angle → rough outer diameter of the car, the opposite plane of the car, inverted fillet → fine aperture, chamfering Angle → fine outer diameter of the car → chamfering → blank inspection → hobbing
Testing:
Depends on the products,
we make different Item Testing Plan,
different Manufacturing procedure etc.
Product reports we provide:
1) Chemical composition report
2) Mechanical performance report
3) Dimensional inspection report
4) Non-destructive testing report
